SKF

Click on image to zoom

SKF

Economy Shakers

Manufacturer : JEIOtech

TECHNICAL SPECIFICATIONS



Model SKF-2025 SKF-2050 SKF-2075 SKF-2025R SKF-2050R SKF-2050R
Shaking
system		 Motion type Orbital Orbital Orbital Reciproc. Reciproc. Reciproc.
Speed range (RPM) 10 to 500 10 to 400 10 to 300 10 to 450 10 to 350 10 to 250
Accuracy at 100 RPM ± 2
Timer Delay On / Off Time : 1min to 999hr 59min
Forward & Backward, Pause : 10sec to 59min 59 sec
Amplitude size
(mm / inch)		 7 / 0.3 13 / 0.5 19 / 0.7 7 / 0.3 13 / 0.5 19 / 0.7
Dimensions Platform (W×D)
(mm / inch)		 320×260 / 12.6×10.2
Exterior (W×D×H) (mm / Inch) 355×375×140 / 14.0×14.8×5.5
Net weight (kg / Ibs) 20 / 44.1
Electrical Requirements
(230V, 50/60Hz)		 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A
Cat. No. AAH3A 105 AAH3A 115 AAH3A 125 AAH3A 205 AAH3A 215 AAH3A 225
Electrical Requirements
(120V, 50/60Hz)		 0.4 A 0.4 A 0.4 A 0.4 A 0.4 A 0.4 A
Cat. No. AAH3A 106 AAH3A 116 AAH3A 126 AAH3A 206 AAH3A 216 AAH3A 226



Model SKF-3050 SKF-3075 SKF-3100 SKF-3050R SKF-3075R SKF-3100R
Shaking
system		 Motion type Orbital Orbital Orbital Reciproc. Reciproc. Reciproc.
Speed range (RPM) 10 to 400 10 to 300 10 to 300 10 to 350 10 to 250 10 to 250
Accuracy at 100 RPM ± 2
Timer Delay On / Off Time : 1min to 999hr 59min
Forward & Backward, Pause : 10sec to 59min 59sec
Amplitude size (mm / inch) 13 / 0.5 19 / 0.7 25 / 1.0 13 / 0.5 19 / 0.7 25 / 1.0
Dimensions Platform (W×D) (mm / inch) 350×350 / 13.8×13.8
Exterior (W×D×H) (mm / Inch) 410×490×140 / 16.1×19.3×5.5
Net weight
(kg / Ibs)		 30 / 74.25
Electrical Requirements
(230V, 50/60Hz)		 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A 0.2 A
Cat. No. AAH3A 305K AAH3A 315K AAH3A 325K AAH3A 405K AAH3A 415K AAH3A 425K
Electrical Requirements
(120V, 50/60Hz)		 0.4 A 0.4 A 0.4 A 0.4 A 0.4 A 0.4 A
Cat. No. AAH3A 306U AAH3A 316U AAH3A 326U AAH3A 406U AAH3A 416U AAH3A 426U
